在工業產品設計生產中，手板原型打樣是一個重要的過程，通過樣板打樣可以很好的對產品進行驗證，手板驗證主主義分為結構手板和外觀手板，這些手板都是可以通過3D打印來完成的，那么3D打印結構手板和外觀手板有什么區別呢？下面濟南手板廠家為您講一講。

In the design and production of industrial products, prototype proofing is an important process, through which products can be well verified. Prototype verification can be divided into structural prototype and appearance prototype, which can be completed through 3D printing. What is the difference between 3D printing structural prototype and appearance prototype?

3D打印結構手板主要用于驗證產品的結構合理性，對于手板尺寸要求比較精準，對手板外觀要求相對較低，國外客戶對這類要求尤為嚴格,結構手板可直觀的反映出結構的合理與否，安裝的難易程度，便于及早發現問題，解決問題。

The 3D printing structural prototype is mainly used to verify the structural rationality of the product. The requirements for the size of the prototype are relatively accurate, while the requirements for the appearance of the prototype are relatively low. Foreign customers are particularly strict with these requirements. The structural prototype can directly reflect the rationality of the structure and the difficulty of installation, so that problems can be found and solved as early as possible.

如果把手板從功能的角度來劃分，就可以分為外觀手板和結構手板。非結構手板也叫外觀板，就是只看外觀的，不需要活動的,所謂外觀手板就是只要求手板的外觀跟設計產品相似，或者跟產品一模一樣，不要求它能起到什么作用，像這樣的產品是不能夠用來銷售的，主要是用來參展的，為的是做好前期的宣傳工作。

If the prototype is divided from the perspective of function, it can be divided into appearance prototype and structure prototype. The non structural prototype is also called the appearance board, which only looks at the appearance and does not need activities. The so-called appearance prototype is that it only requires the appearance of the prototype to be similar to the design product, or the same as the product, and does not require it to play any role. Products like this are not enough for sales, mainly for exhibition, in order to do a good job in early publicity.

而結構手板是可以活動的，可以看到功能的手板，結構手板里面是空心的，可以用來裝電子零件，也可以當做成品來使用,例如汽車模型，結構手板就必須有車身、輪子、車門等等，一般只要是實物外觀上有的都要有，而且都是零散工件組裝起來的，所以結構手板制作起來相對比較復雜，每個位置大小要做到非常精確，否則安裝起來就會出現問題。

The structural prototype can be movable and functional. It is hollow inside and can be used to hold electronic parts or as a finished product. For example, for a car model, the structural prototype must have a car body, wheels, doors and so on. Generally, as long as it is physical, it must have some, and it is assembled with scattered pieces. Therefore, the structural prototype is relatively complex to make, The size of each position must be very accurate, otherwise there will be problems during installation.

以上就是小編為大家分析的有關3D打印結構手板和外觀手板模型有什么區別的介紹，希望可以給大家提供參考。您有疑惑可以隨時來我我么網站http://m.seaoil.cn咨詢！

The above is the introduction about the difference between 3D printing structural prototype and appearance prototype analyzed by Xiao Bian for you, and I hope it can provide you with reference. If you have any doubts, you can come to our website at any time http://m.seaoil.cn consulting service
